Multi Row Series
Gomadhi Multi Row Rotary Weeder is used for Removing of weeds from row crops such as sugarcane. Its modular structure allows the usages of independent tillage heads to suits the cultivation needs of multiple rows. It required 35 - 50 HP tractor with 540 PTO RPM to operate.
Rotary Assembly
Rotary assembly are desgined to be unfastened easily.
Heavy Duty Frame
The ultra-strong frame is so sturdy that it can handle machine without losing strength or resistance
Heavy Duty Gear Box
Side Chain Drive
chain boxes make working in the most challenging conditions
e.g. heavy, stony & clay laden solis.
Gallery
Advantage & Features
- It provide maximum protection of crop integrity.
- Saving labour, time & cost of cultivation.
- The use of Multi row rotary Weeder significantly reduce or even eliminates the need to use chemical weed-killers, which can pollute the environment.
Technical Specification
| Model | Type | Dimension in mm(LxWxH) | Working Width | Tractor Power | No.of Flages | No.of Blades | PTO Input speed | Side Transmission Drive | Rotar Shaft Speed | Size of Blades | Max.working Depth | Rotor Tube Dia | Rotor Swing Dia | Hitching | Type of Blade | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MR | Tractor PTO Operated Rotary Trillers | 2080 x 720 x 1225mm 6.8 x 2.4 x 4ft |
940x2mm 3.1x0.1 ft | 35-50 HP | 6 | 36 | 540 RPM | Chain | 218 RPM | 84x7mm | 100-125mm | 73mm | 455mm | CAT-II 3Point Linkage |
"L" Type | 370 Kgs |
