Spading Machine
Gomadhi Spading machine is an ideal solution to the problem of deep soil tillage in tough conditions, they do not make hard pan (layer of compacted soil in depth), in fact they help eliminating it; they also improve the water circulation and the aeration of the soil. It required 20 hp (4WD Must) —65 hp (with 2.2 km speed- Creeper gear) tractor with 540 PTO RPM to operate.
Heavy Duty Gear Box make working in the most challenging conditions(e.g. heavy, stony and clay laden soils) easy and fast
Spading Machine requires no effort traction so eliminating slippage of the tractor wheels
The Crankshaft is grease lubricated and the disassembly of the moving parts is extremely quick for maintenance and repairs
Adjustable Skid Pad
Both side plates and safety guards have also been modified to improve the soil flow inside the machine during work, and reduce the risk of soil buildup.
Videos
Advantage & Features
- The clods lifted are an ideal size
- The soil is left perfectly level
- Typical horsepower requirements are modest
- Fuel consumption is significantly reduced
- Can be used in various soil types
- Smaller and larger machines possible
- Various working widths 80-180 cm (2.25'-6')
- Working depth 15-35 cm (6-12”)
- Pre lubricated sealed bearings are used
- Depth can be adjusted
- The physical-chemical structure of the soil is improved with the SPADING MACHINE so that yields increase
- The soil is “worked” rather than simply turned over; this means that the root system of crops can still access the most fertile, surface layer.
- The spading machines can operate in wet soil, where as other implements are unusable
Application
- FOR DEEP SOIL TILLAGE It can be used in wet soils, hard soils and hillsides, it helps to eliminate the erosion of light soils as it leaves medium size clods after work.
Technical Specification
| Model | Type | Dimension in mm(L X W X H) | Working Width | Tractor Power | No. of Blades | PTO Input Speed | Rotor Shaft Speed | Max. Working Depth | Hitching | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| SPD804 | TRACTOR PTO OPERATED | 808 x 1125 x 890mm 2.6 x 3.7 x 2.9 ft |
800 mm 2.6 ft |
18-24 HP(4WD MUST) | 4 | 540 RPM | 147, 167, 206 RPM | 150-200 mm | CAT-I | 245 Kgs |
| SPD1606 | 1615 x 1320 x 1150mm 5.3 x 4.3 x 3.8 ft |
1600 mm 5.2 ft |
35-45 Hp Creeper Gear | 6 | 167 RPM | 250-300 mm | CAT-II | 510 Kgs | ||
| SPD1808 | 1810 x 1320 x 1150mm 5.9 x 4.3 x 3.8 ft |
1800 mm 5.8 ft |
55-65 Hp with Creeper Gear | 8 | 620 Kgs |
