Mini Series
Gomadhi 16/20 Blade series rotary tiller is specially designed to operate in lower HP tractors. Its strong design makes this machine more Suitable for soil conditioning, weed control, seed bed preparation (in light soil) and puddling in small fields.
It required 18-24 HP tractor with 540 PTO RPM to operate.
Gallery
Advantage & Features
- It is compatible for mini and lower HP tractor.
- Can loosen & aerate soil 4 to 5 inches deep.
- 4 blades per flange - available in L type blade.
- Sealed bearings prevent moisture/mud entry.
- Helical arrangement of the blades reduces load on the tractor which makes tillage fast and economical.
Application
- Used in small farms, fruit and vegetables, orchards, gardening and nurseries.
Technical Specification
| Model | Type | Dimension in mm (L X W X H) | Working Width | Tractor Power | No.of Flanges | No.of Blades | PTO Input Speed | Side Transmission Drive | Rotor Shaft Speed | Size of Blades | Max. Working Depth | Rotor Tube Dia | Rotar Swing Dia | Hitching | Types of Blade | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AE10C | Tractor PTO Operated Rotary Tillers | 1000 x 630 x 875mm 3.3 x 2.1 x 2.9ft |
760 mm 2.5 ft |
18-24HP | 4 | 16 | 540 RPM | Chain | 218 RPM | 84x7mm | 100-125mm | 60 mm | 400 mm | CAT-I | "L" Type | 168 Kgs |
| AE14C | 1126 x 630 x 875mm 3.7 x 2.1 x 2.9ft |
880 mm 2.9 ft |
5 | 20 | 185 Kgs |
